AUDIO & VIDEO
WyreStorm Essentials™ 4K60 4×2 HDMI Matrix Switcher
If that wasn’t enough, the EXP-MX-0402-H2 also includes analog and digital audio de-embed and ARC, as well as CEC triggering and RS-232 control, hosting a boat load of control features. Coupled with the WyreStorm TS-280 touchscreen and HAOC line of HDMI cables makes for the perfect power pack solution for mid to large scale residential and light commercial applications!
AUDIO & VIDEO
Inputs
4x HDMI In 19-pin HDMI type A
Outputs
2x HDMI Out 19-pin HDMI type A
1x 3.5mm Analog Stereo
1x S/PDIF Toslink
Audio Formats
HDMI: 2ch PCM |
Multichannel: LPCM and up to DTS-X and Dolby Atmos
Analog: 2ch LPCM
Toslink: 5.1ch surround sound
Video Resolution (Max)
1920x1080p @60Hz 16bit
3840x2160p @60Hz 10bit 4:2:0 HDR
4096x2160p @60Hz 8bit 4:4:4
Supported Sandards
DCI | RGB | HDR | HDR10 | Dolby Vision up 30Hz | HLG | BT.2020 | BT.2100
Maximum Pixel Clock
600Mhz
COMMUNICATION & CONTROL
HDMI
HDCP 2.2 | DVI-D supported with adapter (not included)
RS-232
1x 3-Pin Terminal Block
IR
1x Front Panel Sensor
POWER
Power Supply
5V DC 1A
Max Power Consumption
5W
ADDITIONAL FEATURES
