LUTRON HW QS PALLADIOM THERMOSTAT

LUT-PTS

Lutron’s HomeWorks QS Palladiom Thermostat offers a convenient and aesthetically pleasing control of temperature and for intuitive heating and cooling adjustments. Available in a variety of finishes coordenated with Lutron’s Palladiom Keypads.

Temperature can be added to HomeWorks QS whole home scenes via keypad buttons, timeclocks or the Lutron Connect App, which gives your clients the ability to monitor and adjust temperature while home or away.

The Palladiom Thermostate works with most residential HVAC systems. Gas, oil, or electric Furnace, Air conditioning, Fan Coil Units, Heat Pumps, and underfloor heating systems. Please consulte the product specification document for more details.

FEATURES

Aesthetically coordinates with Palladiom keypads
Available in a variety of colour finishes finishes. Please see the Technical Specification section for further details
Backlit screen and buttons that include Dynamic Backlight Management (DBM) to automatically adjust backlight intensity based on ambient lighting conditions
Ability to support separate heating and cooling equipment on one thermostat
Displays temperature in Fahrenheit °F or Celsius °C
Palladiom thermostat continues operation if communication with the HomeWorks QS system is interrupted
Uses Lutron QS link for power and communication with other QS devices
Ships with a sealed wallbox for use in new or existing constructions, specifically for hollow walls that may have air movement in the wall cavity
IEC SELV/NECR Class 2 for 24VDC – 36VDC
IEC, CE, RoHS, cULus, and NOM compliant

SPECIFICATIONS

Regulatory Approvals	IEC, CE, cULus, RoHS, and NOM compliant
Operating Voltage	24VDC – 36VDC IEC SELV/ NECR Class 2 Power provided by QS link power supply
Typical Power Consumption	10mA at 24VDC
Maximum Power Consumption	60mA at 24VDC Test conditions: Backlight on full 3 Power Draw Units (PDUs)
Environment	Ambient operating temperature: 0°C to 40°C / (32°F to 104°F) Relative humidity: 5% to 90% humidity, non condensing Application: Indoor use only IP20 rating
Communications	Thermostat communicates with the HomeWorks QS system via 4 wire QS link protocol. It also communicates with the HomeWorks QS Palladiom HVAC controller and VRV/VRF interfaces via 3 wire HomeWorks QS Palladiom HVAC controller link
Room Temperature Sensor	Temperature display range: 0°C to 37°C (32°F/ 99°F) Temperature setpoint range: 10°C to 32°C (50°F/ 90°F) (programmable) Accuracy: At 25 °C: < +/− 0.5 °C At 70 °F: < +/− 1 °F
Power Failure	Should power be interrupted, the thermostat will retain all settings when restored power is restored
Mounting	Mount on a clean, dry, interior wall approximately 1.2m – 1.5m / 4 ft to 5 ft above the floor, please see the “Mounting” Section of the product data sheet for further details.
Wiring	IEC SELV/NEC Class 2: 24VDC –36VDC 22 AWG (0.5mm²) and 18 AWG (0.75 mm²) solid wiring
Dimensions	Height: 94mm / 3.7″ Width: 102mm / 4″ Depth: 25mm / 1″
