LUTRON HWQS PALLADOM INTERNATIONAL 2 COLUMN KEYPAD, PRE ENGRAVED

LUT-PKP-2C

Lutron’s HWQS Palladiom International 2 Column Keypad LUT-PKP-2C elevates the user experience with sleek and intuitive design and allows the control of Lutron load control devices via a QS link. The keypad is pre engraved for extra convenience and is available in a variety of finishes.

Lutron’s HWQS Palladiom International 2 Column Keypad LUT-PKP-2C elevates the user experience with sleek and intuitive design and allows the control of Lutron load control devices via a QS link.

The keypad is pre engraved for extra convenience and is available in a variety of finishes..

The HomeWorks QS wired Palladiom keypad allows the user to control lights, shades or drapes, temperature and 3rd party equipment. The keypad is wired to a HomeWorks QS processor on the QS link. Buttons and faceplates are flush to each other and feature consistent material, creating a clean, minimalist look.

Large tactile buttons are easy to use and button engraving is easy to read. Buttons and wall plates are made from the same material for a consistent aesthetic. Buttons with white, backlit engraving make it easy to find and operate the keypad in low light conditions.

Status of active button press or scene is indicated through intensity of backlighting which is configurable through the HomeWorks QS software. Dynamic Backlighting Management (DBM) automatically adjusts backlight intensity based on ambient lighting conditions. It can also be programmed in the HomeWorks QS software to adjust intensity by time of day or button presses.

FEATURES

  • Large buttons are easy to use
  • Buttons with white, backlit engraving make it easy to find and operate the keypad in low light conditions
  • Button engraving is easy to read
  • Faceplate snaps on with no visible means of attachment. Surface mount for easy installation, no backbox required
  • Works within Quantum, myRoom Plus and myRoom Prime systems
  • Status of active button press or scene is indicated through intensity of backlighting
  • Dynamic Backlighting Management (DBM) automatically adjusts backlighting intensity based on ambient lighting conditions
  • Backlighting can also be programmed in Quantum and myRoom systems to adjust backlighting intensity
  • IP20 rated

SPECIFICATIONS

LUT-PKP-2C HWQS Palladiom 2 Column International Keypad – Pre engraved
Power 24V to 36 V  30mA
Typical Power Consumption 0.7W
Test conditions:
All backlights on medium intensity, two LEDs on (two pre-sets active), keypad powered at 24V
Communications SELV/PELV/NEC® Class 2 wiring connects keypads to other devices on the QS link. Each keypad counts as 1 device on the QS link. Each keypad column consumes 1 Power Draw Unit (PDU) on the QS link
ESD Protection Meets IEC 801-2. Tested to withstand 15kV electrostatic discharge without damage or memory loss
Power Failure Power failure memory: should power be interrupted, the keypad will return to its previous state when power is restored
Environment Ambient operating temperature: 0°C /  32°F to  40°C /  104°F
Relative humidity: 0% to 90% humidity, non condensing
Application: Indoor use only
Regulatory Approvals Lutron Quality Systems registered to ISO 9001:2015. Complies with UL 508;
IEC 60669-2-1; and CSA C22.22 No. 14-13. EBB-1-3COL only – Complies with UL 2269; IEC 60670-1; and CSA C22.22 No. 18.2 (2006
Wiring SELV/PELV/NEC® Class 2
Terminals: Each terminal accepts up to two 18 AWG (1.0 mm2) wires
Mounting Typical square style wall box dimensions:
Height: 75 mm / 2.95″
Width: 75mm / 2.95″
Depth:  ≥25 mm /  ≥0.98″
Typical round style wall box dimensions:
68 mm / 2.68″
Depth: ≥25 mm / ≥0.98″
