LUTRON OCCUPANCY SENSOR CEILING: WHITE

LUT-LRF3-OCR2B-P-WH

Lutron’s Occupancy Sensor is a Radio Powr Savr sensors, which automatically turn lights on when you walk into a room and off when you leave. Available in corner mount options for the right amount of coverage in any room. This sensor comes in white.

Lutron’s Occupancy Sensor is a Radio Powr Savr sensors, which automatically turn lights on when you walk into a room and off when you leave. Available in corner mount options for the right amount of coverage in any room.

This sensor comes in white.

Go green with Radio Powr Savr. Wasted lighting can account for a majority of a building’s total energy usage. With many building spaces remaining unoccupied for 40% to 70% of the day, lights left on are a real energy drain. Lutron wireless occupancy/vacancy sensors automate the switching and dimming of those lights, saving energy and money.

It’s also convenient. You won’t have to worry about turning lights on or off anymore. Lutron occupancy/vacancy sensors automatically do the job for you every time you enter or exit an office, classroom, conference room or hallway.

Going wireless eliminates the need for costly new wiring. Radio Powr Savr sensors by Lutron install in as little as 15 minutes (default setting) and communicate with compatible Lutron dimmers, switches and light control systems using reliable Clear Connect RF Technology, which ensures a smooth and consistent performance.

FEATURES

  • You can use a mixture of ceiling, wall, corner and  hallway sensors in the same system
  • One sensor should be sufficient for most small to medium sized rooms
  • There is a default 15 minute timeout after the last detected motion, which can be changed to a minimum one minute timeout
  • The battery will last approximately 10 years under normal use, assuming activity occurs 10 hours a day, 7 days a week
  • The sensor features an indicator to alert the user that the battery power is low
  • The sensor uses one CR123
  • lithium batteries

SPECIFICAIONS

Power and Performance Operating voltage: 3V
Operating current: 14 μA nominal
Requires one CR 123 lithium battery
10 year battery life design
Non volatile memory (saved changes are stored during power loss)
RF Range Distance between local load controls and sensor  should not exceed 18m / 60ft line of sight or 9m / 30ft through walls
Sensor Coverage Test Front accessible test button
Lens illuminates orange in response to motion during test mode and is visible from 18m / 60ft
Wireless Communication Test Front accessible test button
Turn associated loads on and off
Timeout Options 1 minute (intended for use in high activity, briefly occupied areas only)
5 minutes
15 minutes (default setting)
30 minutes
Sensitivity Options Low activity (default setting)
Medium activity
High activity
Environment Temperature: 0°C / 32°F to 40°C / 104°F
Relative humidity: less than 90% non condensing
For indoor use only
Dimensions Height: 90.7mm / 3.57″
Depth: 28.7mm / 1.13″
Regulatory Approval CE marked (European Union)
TRA type approved
CITC type approved
Warranty 5 year limited warranty
