LUTRON 75 PDU MULTI DEVICE POWER SUPPLY COMPLETE WITH WIRING HARNESS

LUT-QSPS-DH-1-75-H

The HomeWorks® QS Power Supply provides power to the HomeWorks® QS processor as well as system devices and interfaces. Featuring easy assembly on a DIN rail, the power supply unit delivers 24VDC output voltage and conforms with UL1310 for IEC SELV / NEC® Class 2 applications.

he HomeWorks® QS Power Supply provides power to the HomeWorks® QS processor as well as system devices and interfaces. Featuring easy assembly on a DIN rail, the power supply unit delivers 24 VDC output voltage and conforms with UL1310 for IEC SELV / NEC® Class 2 applications.

For power management details use the HomeWorks® QS design utility and power draw documentation found on the Lutron®  HomeWorks® Resources website (http://resi.lutron.com/).

HomeWorks® QS power supply with wire harnesses have 2 wire harnesses pre-installed.

FEATURES

  • Easy assembly on a DIN rail
  • Power supply unit delivers 24VDC output voltage

SPECIFICATIONS

Power Nominal input voltage: 100VAC to 277VAC  50Hz / 60Hz
Frequency: 50Hz/60Hz
60HzCurrent consumption, fully loaded (typical):0.5A (277V) 0.7A (230V) 1.0A (120V) 1.3A (100V)
Output:24VDC +/- 1%, 2.5A IEC SELV / NECR Class 2
2Power Draw Units (PDUs):
Supplies 75 PDUs maximum
Use above this maximum will reduce the lifetime of the supply and void all Lutron warranties
BTU 28 BTU/hr
Environment Ambient operating temperature: 0°C / 32°F to 55°C / 131°F
Ambient operating humidity: 0% to 90% humidity non condensing
Indoor use only
60°C maximum calibration point temperature
Mounting Mount using  35mm / 1.38″ DIN rail in accordance with EN 60715
Dimensions 90mm / 3.54″ × 90mm / 3.54″ × 61mm / 2.40″
Regulatory Approvals Approvals UL, cUL, CE, NOM compliant
