LUTRON HOMEWORKS® POWPAK LOAD CONTROLLERS

LUT-POWPAK

The HomeWorks® PowPak range of load controllers from Lutron allow easy installation and integration for a variety of applications, simple switched controlled, 3rd party integration and analogue dimming. Complete with Lutron’s Clear connect RF technology.

The HomeWorks® PowPak range of load controllers from Lutron allow easy installation and integration for a variety of applications, simple switched controlled, 3rd party integration and analogue dimming. Complete with Lutron’s Clear connect RF technology.

LMK-16R-DV-B – 16A Relay Module
The RF relay module with Softswitch is a radio frequency (RF) device that uses Lutron patented Softswitch technology to control up to 16A of general purpose loads based on input from RA2 Select, RadioRA 2 and HomeWorks® systems.

LMK-5T-DV-B – 0 to 10V Dimming Module
The RF dimming module with 0 to 10VDC control is a radio frequency (RF) control that operates 0 to 10VDC controlled fluorescent ballasts or LED drivers based on input from RA2 Select, RadioRA 2 and HomeWorks® systems.

LMK-CCO1-24-B – Contact Closure Output Module
The RF CCO Module is a low voltage radio frequency (RF) control that provides a single dry contact closure output based on input from RadioRAR 2 and HomeWorks® QS systems. It can be powered by 24VAC of 24VDC for easy connection and integration into building management, HVAC, VAV and other 3rd party systems.


FEATURES
16A Relay Module

  • Lutron patented Softswitch technology prevents arcing of relay contacts therefore extending product lifetime
  • Various operating voltages available.
  • Capable of switching 16A of general purpose loads
  • Operates at 220 to 240VAC
  • Utilises Lutron Clear Connect RF technology on 868MHz frequency band
  • Mounts to an electrical junction box through a 21mm / 1/2″  (trade size) knockout opening
  • Complies with requirements for use in a compartment handling environmental air (plenum) per NEC® 2011 300.22(C)(3).

0 to 10V Dimming Module

  • 0 to 10VDC control link automatically sources or sinks up to 60mA to third party fixtures
  • Switches line voltage up to 5A
  • Configurable high and low end trim
  • Operates at 220 to 240VDC
  • Utilises Lutron Clear Connect RF technology on 868MHz frequency band
  • RadioRA 2 or HomeWorks® software required for system functionality
  • Mounts to an electrical junction box through a 21mm / 1/2″ knockout opening
  • Complies with requirements for use in a compartment handling environmental air (plenum) per NEC® 2011 300.22(C)(3).

Contact Closure Output Module

  • Single contact closure output including both normally open (NO) and normally closed (NC) dry contacts
  • Maintained or momentary output type
  • Operates at 24VAC or 24VDC
  • Utilises Lutron Clear Connect RF Technology on 868MHz frequency band
  • Screw tabs provided for surface mounting (recommended) or mounts to an electrical junction box through a 1/2″ or 21mm trade size knockout opening
  • Complies with requirements for use in a compartment handling environmental air (plenum) per NECR 2011 300.22(C)(3)

SPECIFICATIONS

LMK-16R-DV-B
16A Relay Module
LMK-5T-DV-B
0 to 10V Dimming Module
LMK-CCO1-24-B
Contact Closure Output Module
Compatible With RA2 Select, RadioRA 2 and HomeWorks systems RA2 Select, RadioRA 2 and HomeWorks systems RA2 Select, RadioRA 2 and HomeWorks systems
Power 120 / 277V~ 50 to 60Hz 16A 0.5 HP at 120V~ 1.5 HP at 277V~ (LMJ model)
220 to 240V~ 50 to 60Hz 16A motor:
6A (LMK , LMM , LMN, LMQ models)
120 / 277V~ 50 to 60Hz 5 A (LMJ model)
220 to 240V~ 50 to 60Hz 5A (LMK, LMM, LMN, LMQ models
IEC PELV/NECR Class 2Operating voltage:
24V~ / 24V-
Operating current, nominal: 45mA (24V~), 35mA (24V-)
Typical Power Consumption < 1.0W Typical power test conditions: all loads off, top LED on < 1.0W Typical power test conditions: all loads off < 1.0W Typical power test conditions: all loads off, CCO LED on
Contact Closure Output Accepts input voltages of 0 to 24V~ / 0 to 24V-
Resistive load: 1.0A (0 to 24V-), 0.5A (0 to 24V~)
Provides both normally open (NO) and normally closed (NC) dry contacts.
Maintained or momentary output type. Output is latching.
Minimum close time: 500ms
Load Maximum load: 16 A general purpose.
No minimum load requirements. Load types include, but are not limited to:
Incandescent, MLV, ELV, resistive, inductive, magnetic fluorescent and electronic fluorescent
0 to10V- Control Link Maximum Load:
60 mA, source or sink automatically configures.
Control link compatible with ANSI E1.3 2001 (R2006), IEC 60929 Annex E
Switched Maximum Load: 5 A lighting.
No minimum load requirements.
Load types include, but are not limited to: MLV, ELV, incandescent, magnetic fluorescent, electronic fluorescent and LEDs
Surge Protection Tested to withstand surge voltages without damage or loss of operation, in accordance with IEEE C62.41-1991 Recommended practice on surge voltages in low voltage AC power circuits Tested to withstand surge voltages without damage or loss of operation, in accordance with IEEE C62.41-1991
Communications Operates using Clear Connect RF technology for reliable wireless communication
RF range is 9m / 30ft from repeaters
Operates using Clear Connect RF technology for reliable wireless communication
RF range is 9m / 30ft from repeaters
Recommended practice on surge voltages in low voltage AC power circuits
Operates using Clear Connect RF Technology for reliable wireless communication
RF range is 9m / 30ftfrom repeaters
Low Voltage CCO Wiring CCO terminals accept 20 to 16 AWG (0.5 to 1.5mm2) solid or stranded wire
Environment Ambient operating temperature: 0°C / 32°F to 55°C /131°F
Ambient operating humidity: 0% to 90% humidity, non condensing
Indoor use only
Ambient operating temperature: 0°C / 32°F to 40°C / 104°F
Ambient operating humidity: 0% to 90% humidity, non condensing
Indoor use only
Ambient operating temperature: 0°C / 32°F to 55°C /131°F
Ambient operating humidity: 0% to 90% humidity, non condensing
Indoor use only
Mounting Mounts to an electrical junction box through a 21 mm / 0.5” trade size knockout opening Mounts to an electrical junction box through a 21mm / 0.5” trade size knockout opening Screw tabs provided for surface mounting (recommended) or mounts to an electrical junction box through a 21mm / 0.5” trade size knockout opening
Dimensions Height: 87mm / 3.42”
Height incl knockout: 100mm / 3.94”
Knockout Opening: 21mm / 0.5” (trade size)
Width: 72mm / 2.82”
Depth: 32mm / 1.25”
Height: 87mm / 3.42”
Height incl knockout:100mm / 3.94”
Knockout Opening: 21mm / 0.5”
Width: 72mm / 2.82”
Depth: 32mm/ 1.25”
Height: 87mm / 3.42”
Height incl knockout: 100mm / 3.94”
Knockout Opening: 21mm / 0.5”
Width: 72mm / 2.82”
Depth: 32mm / 1.25”

Regulatory Approvals UL®, UL 2043 Plenum rated, FCC approved.
Complies with the limits for a Class B device, pursuant to Part 15 of the FCC rules:
CSA, IC, NOM, ANATEL (LMJ model)
CE, TRA, CITC (LMK model)
WPC (LMN model)
cULusR, UL 2043 Plenum rated, FCC approved.
Complies with the limits for a Class B device, pursuant to Part 15 of the FCC rules:
IC, NOM, ANATEL (LMJ model)
CE, TRA, CITC (LMK model)
WPC (LMN model)
ULR, UL 2043 Plenum rated, FCC approved.
Complies with the limits for a Class B device, pursuant to Part 15 of FCC rules, IC, (LMJ model only), CE, TRA, CITC (LMK model
