LUTRON HOMEWORKS® QS HYBRID RF REPEATER

LUT-HQK-REP

HomeWorks® QS Hybrid Repeaters add wireless Radio Frequency (RF) communication and extend the range of RF signals that are sent between dimmers, switches, keypads, visor control receivers, shades and drapes and other devices. Repeaters ensure error free communication between system components and prevent interference from neighbouring systems.

HomeWorks® QS Hybrid Repeaters add wireless Radio Frequency (RF) communication and extend the range of RF signals that are sent between dimmers, switches, keypads, visor control receivers, shades and drapes and other devices. Repeaters ensure error free communication between system components and prevent interference from neighbouring systems.

The first repeater connects to the HomeWorks® QS processor to provide RF communication that extends up to 9m / 30ft in every direction. Up to 4 total Hybrid Repeaters can be used per link to extend the RF range for larger system applications. Each repeater has an RF range of  9m / 30ft between repeater and devices or 18m / 60ft between repeaters, covering a total area of approximately 232m² / 2500sq ft.

FEATURES

  • Test Button enters the RF Repeater test mode
  • Activate button provides repeater activation within system
  • RS485 port to connect to the HomeWorks® QS RF link and to other repeaters through a wired link (daisy chain)

SPECIFICATIONS

Power Hybrid Repeater:
DC adapter: 9VDC 300mA
Link: 24VDC 50mA
DC adapter:
Input: 100 to 240VAC 50/60Hz 6.5W
Output: 9VDC 300mA
Typical Power Consumption Hybrid Repeater: 0.6W Test conditions: one LED on
Powered by a 9VDC adapter
Regulatory Approvals Hybrid Repeater: FCC, IC, COFETEL, CE, CCC, TRA, CTICK, ANATEL, IDA, SUPERTEL, SUTEL
Environment Ambient operating temperature: 0°C to 40°C / 32°F to 104°F
0% to 90% humidity non condensing.
Indoor use only
Unit generates heat, maximum 4 BTU/hr
Low Voltage Wire Type Two pair – one pair 18AWG (1.0mm2), one pair 22AWG to 18AWG (0.5mm2 to 1.0mm2) twisted shielded – NEC® Class 2 / PELV cable. Required for connecting the first repeater to the processor and may be used to connect additional Hybrid Repeaters.
Communications The first Hybrid Repeater communicates with the HomeWorks® QS processor on the RF wired link. Subsequent repeaters may be wired on this link or may communicate over Radio Frequency (RF). All RF devices must be located within 30ft / 9m of a repeater

All repeaters must be within 60ft / 18m  of another repeater

ESD Protection Tested to withstand electrostatic discharge without damage or memory loss in accordance with IEC 61000-4-2
Surge Protection Tested to withstand surge voltages without damage or loss of operation in accordance with IEEE C62.41-1991 Recommended Practice on Surge Voltages in Low Voltage AC Power Circuits
Power Failure Power failure memory. Should power be interrupted, the Repeater will return to its previous state when power is restored
Mounting Mount on a wall, ceiling or level surface using the two #6 (M3) screws provided
Connections Hybrid Repeater: RS485
