LUTRON HOMEWORKS® QS R/L TABLETOP KEYPAD

LUT-KEYPAD

HomeWorks® QS RF Touch Tabletop Keypads from Lutron provide homeowners with a simple and elegant way to operate lights, shades or drapes, motorised screens, thermostats and many other devices. HomeWorks® QS RF Touch Tabletop Keypads feature large, easy to use buttons, plus a unique backlit engraving option that makes the keypads readable any time of the day or night. The keypad buttons are rounded making them easier to read.

HomeWorks® QS RF seeTouch Tabletop Keypads from Lutron provide homeowners with a simple and elegant way to operate lights, shades or drapes, motorised screens, thermostats and many other devices.

HomeWorks® QS RF Touch Tabletop Keypads feature large easy to use buttons, plus a unique backlit engraving option that makes the keypads readable any time of the day or night. The keypad buttons are rounded making them easier to read.

The versatile design of HomeWorks® QS RF Touch Tabletop Keypads allows them to be mounted on a wall, placed on top of a table or used as a cordless keypad. The keypads can be powered by a DC adapter or with 2 AAA batteries.

Battery powered Tabletop Keypads will shut off after a short period of inactivity in order to conserve battery power.

FEATURES

  • At the press of a single button, lights fade on or off to desired levels and shades or drapes open or close to desired positions
  • Light levels and shade or drape positions can be fine tuned by pressing and holding the raise or lower buttons
  • Programmable to select whole house or single room pre-set levels or positions
  • Green LEDs for status and button engraving backlighting
  • Adjustable backlight intensity
  • Prepaid engraving included. Redeemable for one engraved button kit
  • Table top keypad button action is “wake up and activate”. A single button press will “wake up” and activate selected button

SPECIFICATIONS

Power DC adapter:
Input:100V to 240VAC 50/60Hz 6.5W.
Output: 9V 300mA.
Battery powered:
2 AAA alkaline (included) 1.5V each
Typical Power Consumption 0.6W
Test conditions: all backlights on medium intensity, nightlight mode enabled six LEDs on (two pre-sets active per column), keypad powered by a 9V adapter (T120-9DC-3)

Regulatory Approvals DC adapter: UL Listed for U.S. and Canada, NOM. Tabletop Keypad: FCC, IC, COFETEL, ANATEL, CE, TRA, SUPERTEL; SUTEL
Environment Ambient operating temperature: 0°C / 32°F to 40°C / 104°F
Relative humidity:  0% to 90% humidity non condensing
Indoor use only.
Communications HomeWorks® QS RF Touch Tabletop Keypads communicate with the system through Radio Frequency (RF) and must be located within 30ft (9m) of an RF hybrid repeater.
ESD Protection Tested to withstand electrostatic discharge without damage or memory loss, in accordance with IEC 61000-4-2.
Surge Protection Tested to withstand surge voltages without damage or loss of operation, in accordance with IEEE C62.41-1991 Recommended Practice on Surge Voltages in Low Voltage AC Power Circuits.
Power Failure Power failure memory: should power be interrupted, the keypad will return to its previous state when power is restored.
Dimensions Height: 82mm / 3.23″
Width: 91mm / 3.58
Depth: Ranging from 18mm / 0.71″ (bottom) to 25mm / 1″ (top)
Mounting Mounting bracket included for optional wall mount applications.
