LUTRON TABLETOP KEYPAD FACEPLATE

LUT-FACEPLATE

The Table Top Keypads Face Plates from Lutron come with a range of different colour options to allow you to truly customise your Table  Top Keypads. The faceplates are available in the following finishes: Bright Brass, Bright Chrome, Bright Nickel, Satin Brass, Satin Chrome and Satin Nickel.

The TableTop keypads face plates from Lutron come with a range of different colour options to allow you to truly customise your TableTop keypads. The faceplates are available in the following finishes: Bright Brass, Bright Chrome, Bright Nickel, Satin Brass, Satin Chrome and Satin Nickel.

To discuss the customisable options available with the Lutron TableT op Keypads and to discuss seeing the above colour finish samples please speak to your Account Manager or the Habitech Team on 01256 638500

FEATURES

  • Lutron’s HomeWorks® table top keypads provide homeowners with a simple and elegant way to operate lights, shades and drapes, motorised screens and thermostats
  • Feature large, easy to use buttons
  • With an unique backlit engraving option this makes the keypads readable any time of the day or night
  • The versatile design these keypads allows them to be mounted on a wall, placed on top of a table or used as a cordless keypad
  • Powered by a DC adapter or with 2 AAA batteries, the battery powered table top keypads have the added convenience that they will shut off after a short period of inactivity in order to conserve battery power
  • At the press of a single button, lights fade ON or OFF to desired levels and shades or drapes open or close to desired positions
  • Light levels and shade/drapery positions can be fine tuned by pressing and holding the raise/lower buttons
  • Programmable to select whole house or single room pre-set levels or positions

SPECIFICATIONS

LUT-FACEPLATE Keypad Faceplate
Power DC adapter:
Input: 100–240V  50/60Hz  6.5W
Output: 9V  300mA
Battery powered: 2 AAA alkaline (included) 1.5V each
Typical Power Consumption 0.6W
Test conditions: all backlights on medium intensity, nightlight mode enabled, six LEDs on (two pre-sets active per column), keypad powered by a 9V adapter
Finishes Bright brass – BB
Bright chrome – BC
Bright nickel – BN
Satin brass – SB
Satin chrome -SC
Satin nickel – SN
Configuration 5 button – T5RL
10 buttons – T10RL
15 buttons – T15RL
Environment Ambient operating temperature: 0°C / 32°F to 40°C / 104°F
Relative humidity: 0% to 90% humidity non condensing
Indoor use only
Communications HomeWorks QS RF table top keypads communicate with the system through Radio Frequency (RF) and must be located within 9m / 30 ft of an RF hybrid repeater
ESD Protection Tested to withstand electrostatic discharge without damage or memory loss, in accordance with IEC 61000-4-2
Surge Protection Tested to withstand surge voltages without damage or loss of operation, in accordance with IEEE C62.41-1991 Recommended Practice on Surge Voltages in Low Voltage AC Power Circuits
Power Failure Power failure memory. Should power be interrupted, the keypad will return to its previous state when power is restored
Regulatory Approvals Table top keypad: FCC, IC, COFETEL, ANATEL, CE, TRA, SUPERTEL; SUTEL
Mounting Mounting bracket included for optional wall mount applications
Dimensions Height: 74mm / 2.91″
Width: 91mm / 3.58″
Depth: Top: 25mm / 1″  Bottom: 18mm / 0.75″
